General Specifications

Socket

LGA 1700

Form Factor

Micro ATX

Chipset

Intel B760

Max Memory

256 GB

Memory Type

DDR5

Memory Slots

Colors

BLACK GREY

Lighting

None

PCIe Slots

1 x PCIe 5.0 x16 2 x PCIe 4.0 x1 1 x PCIe 4.0 x4

M.2 Slots

M 2242/2260/2280 PCIe 4.0 x4 M 2242/2260/2280 PCIe 4.0 x4 M 2242/2260/2280 PCIe 3.0 x2

SATA 6Gb/s

SATA 3Gb/s

U.2 Ports

Onboard Ethernet

Realtek 1 Gb/s

WiFi

WiFi 6 Bluetooth 5.3

USB 2.0

USB 3.2 Gen 1

USB 3.2 Gen 2

USB 3.2 Gen 2x2

USB 4.0

USB 4 80Gbps

Unknown

CPU Fan Headers

Case Fan Headers

Pump Headers

CPU Optional Fan Headers

ARGB 5V Headers

RGB 12V Headers

Unknown

Power Button Header

Yes

Reset Button Header

Yes

Power LED Header

Yes

HDD LED Header

Yes

Temperature Sensor Headers

Unknown

Thunderbolt Headers

Unknown

COM Port Headers

Main Power

24-pin

CPU Power

8-pin

ECC Support

RAID Support

Yes

Back-Connect Connectors

BIOS Flashback

Clear CMOS Button

Audio Chipset

Realtek

Audio Channels

7.1

Back Panel Ports

2 x USB 10Gbps ports 4 x USB 5Gbps ports 1 x DisplayPort 1 x HDMI port 1 x Wi-Fi Module 1 x Realtek 1Gb Ethernet port 3 x Audio jacks

Product Information

Manufacturer

ASUS

Series

MAX GAMING

Variant

B760M WIFI

Release Year

2026

Manufacturer Color

Black

UPC

199291026575

EAN

0199291026575

Part Numbers

B760M MAX GAMING WIFI

BuildCores ID

6vo7jzuim

See an issue?Report an issue on OpenDB

Motherboard

ASUS B760M MAX GAMING WIFI

Name: ASUS B760M MAX GAMING WIFI
Brand: ASUS
SKU: 6vo7jzuim

SocketLGA 1700

Form FactorMicro ATX

ChipsetIntel B760

Best Price

$149.99

via

	—	$149.99
Loading... Loading

MERCHANT	SHIPPING	PROMO	AVAILABILITY	TOTAL
	—	—	In stock	$149.99 via Amazon Loading... Loading

MERCHANT	SHIPPING	PROMO	AVAILABILITY	TOTAL
	—	—	In stock	$149.99 via Amazon Loading... Loading

* BuildCores may receive compensation for affiliate sales through these linksReport a pricing issue

Price History

Loading price history...

* Amazon pricing is not included in price history graphs.
