Product Information

Manufacturer

ASUS

Series

A520

Variant

TUF GAMING M-PLUS WIFI

Release Year

Unknown

Manufacturer Color

Unknown

UPC

195553154284

EAN

0195553154284

Part Numbers

TUF GAMING A520M-PLUS WIFI 90MB17F0-M0EAY0

BuildCores ID

avp7v9wn5

General Specifications

Socket

AM4

Form Factor

Micro ATX

Chipset

AMD A520

Max Memory

128 GB

Memory Type

DDR4

Memory Slots

Colors

BLACK ORANGE

PCIe Slots

1 x PCIe 3.0 x16 2 x PCIe 3.0 x1

M.2 Slots

M 2242/2260/2280 PCIe 3.0 x4

SATA 6Gb/s

SATA 3Gb/s

U.2 Ports

Onboard Ethernet

Realtek 1 Gb/s

WiFi

Wi-Fi 5 Bluetooth v5.0

USB 2.0

USB 3.2 Gen 1

USB 3.2 Gen 2

USB 3.2 Gen 2x2

USB 4.0

USB 4 80Gbps

Unknown

CPU Fan Headers

Case Fan Headers

Pump Headers

Unknown

CPU Optional Fan Headers

Unknown

ARGB 5V Headers

RGB 12V Headers

Power Button Header

Yes

Reset Button Header

Yes

Power LED Header

Yes

HDD LED Header

Yes

Temperature Sensor Headers

Unknown

Thunderbolt Headers

Unknown

COM Port Headers

Unknown

Main Power

24-pin

CPU Power

8-pin

ECC Support

Yes

RAID Support

Yes

Back-Connect Connectors

BIOS Flashback

Yes

Clear CMOS Button

Audio Chipset

Realtek

Audio Channels

7.1

Back Panel Ports

1 x PS/2 Keyboard/Mouse combo port 1 x DisplayPort 1.2 1 x HDMI port 1 x D-Sub (VGA) port 4 x USB 3.2 Gen 1 ports (Type-A) 2 x USB 2.0 ports (Type-A) 1 x Realtek 1Gb Ethernet port 1 x ASUS Wi-Fi Module 3 x Audio jacks 1 x BIOS FlashBack button

See an issue?Report an issue on OpenDB

Motherboard

Asus TUF GAMING A520M-PLUS WIFI AM4 DDR4 Micro ATX

Name: Asus TUF GAMING A520M-PLUS WIFI AM4 DDR4 Micro ATX
Brand: ASUS
SKU: avp7v9wn5

Best Price

$99.99

via

	—	$99.99
Loading... Loading
	FREE s/h	$99.99
Loading... Loading

MERCHANT	SHIPPING	PROMO	AVAILABILITY	TOTAL
	—	—	In stock	$99.99 via Amazon Loading... Loading
	FREE s/h	—	In stock	$99.99 via B&H Photo Loading... Loading

MERCHANT	SHIPPING	PROMO	AVAILABILITY	TOTAL
	—	—	In stock	$99.99 via Amazon Loading... Loading
	FREE s/h	—	In stock	$99.99 via B&H Photo Loading... Loading

* BuildCores may receive compensation for affiliate sales through these links

Price History

Loading chart...

* Amazon pricing is not included in price history graphs.

Product Information

Manufacturer

ASUS

Series

A520

Variant

TUF GAMING M-PLUS WIFI

Release Year

Unknown

Manufacturer Color

Unknown

UPC

195553154284

EAN

0195553154284

Part Numbers

TUF GAMING A520M-PLUS WIFI 90MB17F0-M0EAY0

BuildCores ID

avp7v9wn5

General Specifications

Socket

AM4

Form Factor

Micro ATX

Chipset

AMD A520

Max Memory

128 GB

Memory Type

DDR4

Memory Slots

Colors

BLACK ORANGE

PCIe Slots

1 x PCIe 3.0 x16 2 x PCIe 3.0 x1

M.2 Slots

M 2242/2260/2280 PCIe 3.0 x4

SATA 6Gb/s

SATA 3Gb/s

U.2 Ports

Onboard Ethernet

Realtek 1 Gb/s

WiFi

Wi-Fi 5 Bluetooth v5.0

USB 2.0

USB 3.2 Gen 1

USB 3.2 Gen 2

USB 3.2 Gen 2x2

USB 4.0

USB 4 80Gbps

Unknown

CPU Fan Headers

Case Fan Headers

Pump Headers

Unknown

CPU Optional Fan Headers

Unknown

ARGB 5V Headers

RGB 12V Headers

Power Button Header

Yes

Reset Button Header

Yes

Power LED Header

Yes

HDD LED Header

Yes

Temperature Sensor Headers

Unknown

Thunderbolt Headers

Unknown

COM Port Headers

Unknown

Main Power

24-pin

CPU Power

8-pin

ECC Support

Yes

RAID Support

Yes

Back-Connect Connectors

BIOS Flashback

Yes

Clear CMOS Button

Audio Chipset

Realtek

Audio Channels

7.1

Back Panel Ports

See an issue?Report an issue on OpenDB

Asus TUF GAMING A520M-PLUS WIFI AM4 DDR4 Micro ATX

Completed Builds
