ASRock X870 Taichi Creator AM5 DDR5 ATX image

ASRock X870 Taichi Creator AM5 DDR5 ATX main image

General Specifications

Socket

AM5

Form Factor

ATX

Chipset

AMD X870

Max Memory

256 GB

Memory Type

DDR5

Memory Slots

Colors

BLACK GOLD

Lighting

None

PCIe Slots

1 x PCIe 5.0 x16 1 x PCIe 5.0 x8 1 x PCIe 3.0 x4

M.2 Slots

M 2280 PCIe 5.0 x4 M 2280 PCIe 5.0 x4 M 2280 PCIe 4.0 x4 M 2280 PCIe 3.0 x4

SATA 6Gb/s

SATA 3Gb/s

U.2 Ports

Onboard Ethernet

Aquantia AQC113CS 10 Gb/s Realtek RTL8126 5 Gb/s

WiFi

Wi-Fi 7 Bluetooth 5.4

USB 2.0

USB 3.2 Gen 1

USB 3.2 Gen 2

USB 3.2 Gen 2x2

USB 4.0

USB 4 80Gbps

Unknown

CPU Fan Headers

Case Fan Headers

Pump Headers

CPU Optional Fan Headers

Unknown

ARGB 5V Headers

RGB 12V Headers

Power Button Header

Yes

Reset Button Header

Yes

Power LED Header

Yes

HDD LED Header

Yes

Temperature Sensor Headers

Thunderbolt Headers

Unknown

COM Port Headers

Unknown

Main Power

24-pin

CPU Power

8-pin 8-pin

ECC Support

Yes

RAID Support

Yes

Back-Connect Connectors

BIOS Flashback

Yes

Clear CMOS Button

Yes

Audio Chipset

Realtek ALC4082

Audio Channels

7.1

Back Panel Ports

2 x Antenna Ports 1 x HDMI Port 1 x Optical SPDIF Out Port 2 x USB4 Type-C Ports 2 x USB 3.2 Gen2 Type-A Ports 6 x USB 3.2 Gen1 Type-A Ports 2 x USB 2.0 Ports 2 x RJ-45 LAN Ports 1 x Clear CMOS Button 1 x BIOS Flashback Button 1 x Line Out Jack 1 x Microphone Input Jack

Product Information

Manufacturer

ASRock

Series

TAICHI

Variant

X870 CREATOR

Release Year

2025

Manufacturer Color

Black

UPC

4711581492066

EAN

4711581492066

Part Numbers

X870 Taichi Creator X870 TAICHI CREATOR

BuildCores ID

ejnlqvxp7

See an issue?Report an issue on OpenDB

Motherboard

ASRock X870 Taichi Creator AM5 DDR5 ATX

Name: ASRock X870 Taichi Creator AM5 DDR5 ATX
Brand: ASRock
SKU: ejnlqvxp7

SocketAM5

Form FactorATX

ChipsetAMD X870

Best Price

$319.99

via

	—	$319.99
Loading... Loading
	FREE s/h	$319.99
Loading... Loading
	FREE s/h	$319.99
Loading... Loading

MERCHANT	SHIPPING	PROMO	AVAILABILITY	TOTAL
	—	—	In stock	$319.99 via Amazon Loading... Loading
	FREE s/h	—	In stock	$319.99 via Walmart Loading... Loading
	FREE s/h	—	In stock	$319.99 via Newegg Loading... Loading

MERCHANT	SHIPPING	PROMO	AVAILABILITY	TOTAL
	—	—	In stock	$319.99 via Amazon Loading... Loading
	FREE s/h	—	In stock	$319.99 via Walmart Loading... Loading
	FREE s/h	—	In stock	$319.99 via Newegg Loading... Loading

* BuildCores may receive compensation for affiliate sales through these linksReport a pricing issue

Price History

Loading price history...

* Amazon pricing is not included in price history graphs.

General Specifications

Socket

AM5

Form Factor

ATX

Chipset

AMD X870

Max Memory

256 GB

Memory Type

DDR5

Memory Slots

Colors

BLACK GOLD

Lighting

None

PCIe Slots

1 x PCIe 5.0 x16 1 x PCIe 5.0 x8 1 x PCIe 3.0 x4

M.2 Slots

M 2280 PCIe 5.0 x4 M 2280 PCIe 5.0 x4 M 2280 PCIe 4.0 x4 M 2280 PCIe 3.0 x4

SATA 6Gb/s

SATA 3Gb/s

U.2 Ports

Onboard Ethernet

Aquantia AQC113CS 10 Gb/s Realtek RTL8126 5 Gb/s

WiFi

Wi-Fi 7 Bluetooth 5.4

USB 2.0

USB 3.2 Gen 1

USB 3.2 Gen 2

USB 3.2 Gen 2x2

USB 4.0

USB 4 80Gbps

Unknown

CPU Fan Headers

Case Fan Headers

Pump Headers

CPU Optional Fan Headers

Unknown

ARGB 5V Headers

RGB 12V Headers

Power Button Header

Yes

Reset Button Header

Yes

Power LED Header

Yes

HDD LED Header

Yes

Temperature Sensor Headers

Thunderbolt Headers

Unknown

COM Port Headers

Unknown

Main Power

24-pin

CPU Power

8-pin 8-pin

ECC Support

Yes

RAID Support

Yes

Back-Connect Connectors

BIOS Flashback

Yes

Clear CMOS Button

Yes

Audio Chipset

Realtek ALC4082

Audio Channels

7.1

Back Panel Ports

Product Information

Manufacturer

ASRock

Series

TAICHI

Variant

X870 CREATOR

Release Year

2025

Manufacturer Color

Black

UPC

4711581492066

EAN

4711581492066

Part Numbers

X870 Taichi Creator X870 TAICHI CREATOR

BuildCores ID

ejnlqvxp7

See an issue?Report an issue on OpenDB
